DBX 223xs | 2-way stereo/ 3-way mono split with xlr

The secret to making speakers sound great lies with the crossover you use. With the dbx® 223xs Crossover you'll get great performance, ultra low-noise, rugged reliability and four decades of dbx knowledge and expertise in building the world's finest processors. The 223xs uses precision filters to separate the audio signal and direct the correct frequencies to your loudspeaker drivers. By directing only the specific frequency bands to each speaker driver the 223xs leaves your amplifiers free to use their full power on the usable signal eliminating distortion and giving your PA system a cleaner and better sound. Features XLR balanced ins and outs Mode switch for stereo 2-way or mono 3-way operation Low frequency summed (subwoofer) output x10 range switch on both channels 40Hz high pass (low cut) filter both channels Phase reverse switch on all outputs Individual level controls on all outputs 24dB per octave Linkwitz-Riley filters (the professional standard) Stereo/Mono status LEDs indicate the selected mode dbx® 2 year parts and labor as standard CSA NRTL/C approved CE compliant
